How to determine LAN network topology and understand its types

If you're wondering how to determine the LAN topology of your home, office, or business, the first step is to understand what "topology" means and why it affects network speed, security, and stability. It's not just a diagram of nodes and cables; it's the foundation of how frames and packets move between devices.

Before you start mapping routers, switches, and cables, it's important to understand that there isn't just one topology : there's almost always a physical topology (what you see and touch) and a logical one (how the data actually flows). Being able to identify both will allow you to diagnose bottlenecks, connectivity issues, and decide whether your current design makes sense or needs a significant overhaul.

What is LAN network topology (physical and logical)?

When we talk about network topology, we're referring to how devices (nodes) and connections (links) are organized in a communications network. This includes computers, servers, printers, switches, routers, Wi-Fi access points, IP cameras, and so on, as well as the media that connect them: copper cables, fiber optics, radio, wireless links, etc.

In any LAN, there are two distinct but related perspectives: physical topology and logical topology . It's important to differentiate between them because you can have one thing at the cabling level and something very different in terms of data flow.

The physical network topology describes where devices are located and how they connect to each other in tangible terms: which equipment goes to which port on which switch, what type of cable is used, in which rack it is mounted, in which room it is located, etc. A physical diagram typically represents nodes as device icons and links as lines symbolizing cables or wireless links.

The logical network topology shows how frames and packets actually travel between nodes, which devices share a broadcast domain, how traffic is segmented into VLANs, what routes IP packets follow, what media access protocols are used, and so on. At a logical level, an Ethernet network with switches typically behaves like a logical bus , while technologies like Token Ring represent a logical ring , even though the cables are physically connected in a star topology.

The data link layer is what "sees" the logical topology, because it controls who can use the medium at any given time and which frames are accepted or discarded. Therefore, understanding the logical topology is key to understanding why collisions, congestion, or packet loss occur, even when the cabling appears perfect.

Basic components of a LAN topology

To identify your LAN topology, you need to be clear about which elements are part of the map : not only the PCs, but everything that participates in sending and receiving data.

First are the endpoints : user computers, servers, laptops, Wi-Fi connected mobile devices, network printers, cameras, set-top boxes, etc. These are the devices that generate and consume information, and they are usually connected to the network through an Ethernet NIC or a wireless interface.

Next, we have the links , which are the means by which the signals travel. In a typical LAN, twisted-pair cables (UTP, FTP, or STP) with RJ-45 connectors predominate, although you may also find coaxial cable or fiber optic cable in certain sections, and of course, wireless links such as Wi-Fi or other radio standards.

Alongside these are the interconnection and security devices: switches, routers, access points, firewalls, bridges, gateways, etc. These distribute, route, or filter traffic between segments and determine much of the logical behavior: what can be seen with what, how it reaches the Internet, which routes are chosen, what traffic is blocked, etc.

Finally, we must not forget the passive elements of the infrastructure : patch panels, racks, cable trays, wall outlets, connectors, antennas, etc. They do not process data, but they determine the physical topology and the ease (or difficulty) of expanding, documenting, or troubleshooting it.

Main types of LAN network topology

A LAN can have several possible configurations, both physical and logical. Each type of topology has advantages, disadvantages, and use cases , and many real-world networks are hybrid topologies adapted to specific performance, cost, or reliability needs.

Point-to-point topology

Point-to-point topology is the simplest: two devices connected directly via a single link. This could be an Ethernet cable between two PCs, a serial link between two routers, or a VPN connecting two remote sites without any apparent intermediaries.

Its greatest strengths are its simplicity and security : the channel is not shared with anyone else, no complex logic is needed to access the medium, and the diagnostics are very straightforward. On the other hand, it's not scalable: it only connects two nodes; if you want a third device, you'll need something else.

Bus topology

In a bus topology, all devices share a main or trunk cable to which they connect via branches. Historically, coaxial cable was used (for example, 10BASE2 with RG-58 and BNC connectors), with terminators at the ends to prevent signal reflections.

The physical bus reduces cable consumption and makes it easier to add or remove nodes, but it has several problems: if the backbone breaks, the entire network goes down , each device adds more load, and the risk of collisions increases. Older Ethernet bus LANs used CSMA/CD (Carrier Sense Multiple Access with Collision Detection) to detect collisions and retransmit damaged frames.

From a logical standpoint, many modern networks with switches still function as a logical bus : frames are broadcast within a broadcast domain, even though there is a physical star topology of cables. However, the coaxial bus topology is practically obsolete in new designs due to its low speed and poor scalability.

ring topology

In a ring topology, each device connects to exactly two neighbors , forming a closed loop through which frames circulate in one or both directions. The most classic example is Token Ring, where a "token" travels around the ring and only the device that possesses it can transmit.

This approach reduces collisions because access to the medium is controlled , and it allows each node to regenerate the signal, maintaining acceptable speeds even with a significant number of hops. However, any failure in a link or station can affect the entire ring, and adding or removing nodes requires reconfiguring the circuit.

There are variations such as the dual ring , where a second loop is added in the opposite direction to achieve redundancy and full-duplex: if one segment fails, traffic can be diverted through the other ring. Today, the ring design is primarily used in optical rings for operators and metropolitan area networks, rather than in office LANs.

Star topology

The star topology is by far the dominant topology in modern LANs . All devices connect to a central element (usually a switch) via their own cable. There are no direct links between PCs: everything passes through the switch.

The advantages are clear: if a network card fails or a cable breaks on a device, only that node is affected , not the entire network. Expanding the LAN is as simple as connecting a new cable to the switch. The design facilitates troubleshooting, VLAN segmentation, speed upgrades (for example, moving from 1G to 10G on backbones), and the integration of copper and fiber.

Behind the star topology lie concepts like the difference between a hub and a switch . A hub operates at the physical layer and replicates everything it receives through one port to all others, generating collisions and wasting bandwidth. A switch, on the other hand, operates at the data link layer, learns MAC addresses, and sends each frame only through the necessary port, preventing unnecessary flooding.

Star Ethernet networks rely on various standards (10BASE-T, 100BASE-TX, 1000BASE-T, 10GBASE-T, etc.), using twisted-pair cabling of different categories (Cat 5e, Cat 6, Cat 6A, etc.) and maximum lengths of 100 meters per copper segment. For longer distances or very low latency, fiber optic cables with SFP/SFP+ transceivers and variants such as 10GBASE-S or 10GBASE-E are used.

Home and office Wi-Fi networks also typically feature a star topology around an access point : all wireless clients connect to this AP, which in turn is usually connected by cable to a switch or router. Although the medium is radio, the concept of a central node remains very similar.

Tree topology (extended star)

A tree topology is essentially a star of stars : several switches connected hierarchically, where one or more devices act as the root or core, and the rest as branches hanging from them. It's the natural evolution when a single star becomes insufficient in size or distance.

In a multi-story building, it's common to have a main switch in the communications room and one switch per floor or department. Each user device connects to its local switch, and these are interconnected to the main switch via higher-capacity uplinks. This optimizes cabling, reduces the length of horizontal runs, and maintains a clean and organized layout.

This structure is highly scalable and makes it easy to apply policies: subnets and VLANs can be defined by floor or area , intermediate routers or firewalls can be used to control traffic between segments, and each branch can be kept relatively isolated from certain incidents.

Furthermore, the tree supports both copper and fiber links, mixing technologies if necessary. However, careful design is essential to avoid excessively long switch chains that could create bottlenecks or complicate protocols like Spanning Tree when handling loops and redundancies.

Mesh topology

In a mesh topology, each node is connected to several others, creating multiple alternative paths between origin and destination. In a full mesh, all nodes are connected to each other; in a partial mesh, only some nodes have multiple connections.

The mesh network's greatest strength is its fault tolerance : if a link or even a node fails, traffic can continue along alternative routes. This makes it very attractive in critical environments (military infrastructure, carrier networks, large enterprise backbone networks, wireless mesh networks, etc.).

In return, design and maintenance become more complex: the number of links grows rapidly with each new node, which means more ports, more cabling, higher costs , and more complex routing. Dynamic protocols are needed that can calculate optimal routes, manage metrics, and prevent loops.

In the wireless world, mesh networks (for example, with standards such as IEEE 802.11s, Zigbee, Z-Wave or WirelessHART) allow coverage to be extended by connecting access points or low-power nodes in a chain , so that traffic jumps from one to another until it reaches the gateway.

hybrid topology

In practice, almost all networks of a certain size are hybrid topologies , resulting from combining several basic schemes. You might have a metropolitan optical ring connecting several sites, and at each site a star or tree topology of switches serving the internal offices.

The hybrid topology allows you to leverage the best of each type : the reliability of a ring or mesh in the core, combined with the simplicity and low cost of a star for access. However, it also carries the worst aspects if not designed well: greater complexity, more points to document, and more dependencies between technologies.

When planning or analyzing a hybrid LAN, it's important to clearly understand the difference between physical and logical topology at each layer. At the physical level, you might see star and tree topologies; at Layer 2, you might have a mesh topology with redundant links and Spanning Tree topology; and logically, at Layer 3, a series of IP routes between subnets.

Physical topologies vs. logical topologies in LAN and WAN

One of the most common mistakes when trying to determine your LAN topology is confusing what you see with what's happening inside . Just because all the cables are plugged into a switch doesn't mean it will logically function as you imagine.

The physical topology of your LAN is described by cabling diagrams, rack layouts, and the arrangement of switches, routers, access points, and endpoints. You can map it by physically tracing the cables, consulting labels, patch panels, and installation documentation.

The logical topology is deduced from how the devices are configured: what VLANs are defined, what IP ranges are used, what routers or firewalls separate subnets, what static or dynamic routes are applied, what protocols control access to the medium (CSMA/CD, token passing, etc.), and how the load is distributed between links.

For example, a twisted-pair Ethernet network with switches is typically a physical star topology, but at the frame level, you share a broadcast domain similar to a logical bus if you don't segment it with VLANs or routers. In contrast, a Token Ring network may be wired in a star configuration around a hub, but its logical topology remains a ring.

In WAN environments (links between sites, carrier connections, etc.) topology descriptions are also used: point-to-point, hub-and-spoke, partial mesh, etc. Even when there are many intermediate physical hops (provider routers, optical links, aggregation equipment), you can logically have, for example, a point-to-point connection between two routers in your company.

How to find out the topology of your LAN network step by step

Once the concepts are clear, the next question is how to practically determine the actual topology of your local network. Simply looking at "a blue cable going into the switch" isn't enough; you need to combine physical observation with logical analysis.

The usual approach is to begin with a physical inspection : locate the communications room, identify the switches, routers, and panels, check which ports are occupied, how the cables are labeled, and which branches connect to which floors or rooms. A simple sketch on paper will give you clues as to whether you're dealing with a simple star topology, a hierarchical tree, or a hybrid with several daisy-chained switches.

Next, connect to the management interface of the key devices (web, CLI, SNMP, etc.) to view their configuration. There you can check VLANs, MAC addresses, IP routes , link aggregation groups (LAGs), wireless networks, NAT, firewall rules, and so on. With this information, it's easier to map the logical topology: which nodes share a segment, which traffic flows through which path, and which links are critical.

In more complex networks, automatic mapping tools or topology functionalities integrated into monitoring platforms (for example, cloud-based systems like Azure Network Watcher) can help you generate topology diagrams from device information. These views typically show virtual networks, subnets, interfaces, security groups, routes, and traffic flow between zones.

Once you have a diagram, it's a good idea to validate it with tests: use commands like ping, traceroute, pathping , check ARP tables, capture traffic at key points, or use connection monitors to confirm that the traffic follows the expected routes and that the logical topology matches what you've drawn.

Importance of choosing and maintaining a good topology

Network topology is not merely an aesthetic detail of the network design: it directly impacts performance, security, and operating costs. A poorly planned design can lead to persistent bottlenecks, Wi-Fi coverage shadows, single points of failure, and a nightmare when troubleshooting.

A good physical topology facilitates orderly network growth: you can add nodes and segments without rewiring, scale the core to higher speeds, or introduce redundancy where it's most needed. At the same time, a good logical topology allows you to isolate sensitive traffic, comply with security policies, prioritize critical applications, and respond more effectively to attacks or load spikes.

Furthermore, having an up-to-date topology diagram is a fundamental working tool for any systems or network team. It serves to diagnose problems, plan changes, justify investments, and train new technicians. Without this map, any intervention is, to a large extent, a shot in the dark.

In short, if you're interested in knowing what LAN topology you have and which one is best for you, the practical approach involves combining the theory of topology types (bus, ring, star, tree, mesh, hybrid, point-to-point), carefully reviewing the physical installation, analyzing the configuration of switches and routers, and documenting the result in a clear diagram. With this comprehensive view, you can assess whether your current network meets your actual performance, reliability, and security needs, or if it's time to redesign it with a topology better suited to your current requirements.
